ZIGY Flush Wall Corner

(A8-ZIGY-FWC)

ALUZ brings you the ZIGY Flush Wall Corner — designed for Mud-In Perimeter applications.
With a dual light source and a variety of LED colors, ZIGY can be manufactured to your exact specifications.

General Features

Applications
Mud-In, Accent, Decorative, Surface, Recessed Lighting
Lens
50% Semi-Frosted or 100% Frosted
Viewing Angle
120°
Length
Built to Order (+/- 1/8" Tolerance)
Construction
Aluminum Extrusion
Weight
0.81 lbs per foot
Mounting
Mud-In
Listing
Dry or Damp Location
UL2108, 67.1.9, 60.4, CSA C22.2#9
UL8750, CSA250
Driver
Remote (Sold Separately)
Closet Rating
Up to 3.6 Watts per Foot Maximum
Temperature Ratings
Operating / Startup: -20° to 48°C (-4° to 120°F)
Storage: -40° to 76°C (-40° to 170°F)

Lamp Features

Lamp Type
LEDs
CRI
> 95
Efficacy
(Based on 35K CCT LED)
103 Lumens per Watt

Electrical

Dimming
0-10V, Forward / Reverse Phase, Lutron, DMX, DALI
Maximum Run
(Class 1 Applications)
18’ (13W), 21’ (11W), 26’ (9W),
33’ (7.2W), 36’ (3W, 5W)
Maximum Run
(Class 2 Applications)
6’ (13W), 7’ (11W), 9’ (9W),
11’ (7.2W), 17’ (5W), 28’ (3W)
Luminaire Voltage
24VDC

LED Color Options

color swatch
color swatch
color swatch
color swatch
color swatch
color swatch
color swatch
color swatch
color swatch
color swatch

End View

Beam Angle

120° x 120° Beam

Lens

50% Semi Frosted Lens
(SF)
Slight Diode Image

100% Frosted Lens
(F)
No Diode Image: Line of Light

End Caps

Left End Cap
(A8-ZIGY-FWC-ECL)

Right End Cap
(A8-ZIGY-FWC-ECR)

Connectors
